Draper Automotive Clamp Meter Auto-Ranging
The Draper Automotive Clamp Meter is an expert quality, auto and manual ranging clamp meter capable of voltage, current, resistance, diode, continuity, capacitance, frequency, duty cycle and temperature testing. It has a maximum jaw-opening diameter of 36mm, backlit LCD screen, auto power off, linear bar graph functions and a useful inspection light. Supplied with test leads, temp probe, and case.
Features and Benefits:
Backlit LCD screen
Test leads
Temp probe
Additional Note:
Technical Spec:
600mV/6V/60V/600V
AC Voltage 6V/60V/600V
DC Amps 60A/600A
AC Amps 60A/600A
Resistance 600ohms/6kohms/60kohms/6Mohms/60Mohms
Capacitance 999nF/99.99nF/999.9nF/9.999µF/99.99µF/999.9µF/9.999mF/99.99mF
Frequency 100Hz/1000Hz/10kHz/100kHz/1MHz/10MHz
Temp -50 to 300ºC
Type | Specialist Tools |
|---|---|
Resistant Type | CAT III 600V |
primary colour | Blue |
Colour | Blue and Black |
Box Contents | Clamp meter, test leads, temp probe and a case |
Weight | 400 |
Resistance | 600ohms to 60Mohms |
AC Voltage | 600 |
Frequency | 100Hz to 10MHz |
Metric or Imperial | Metric |
No. of Pieces in a Pack | 1 |
Powered By | 3 x AAA batteries (not supplied) |
Suitable For | Automotive electrical diagnostics; measuring AC/DC voltage, current, resistance, capacitance, frequency, duty cycle, diode, continuity and temperature testing |
Dimensions | 228 x 158 x 58mm |
SKU | 285998 |
