  • Boardman MTR 8.9 Mountain Bike

    The Boardman MTR 8.9 Mountain Bike builds on the capabilities of the PRO FS but with new tube profiles and tweaked geometry (including a slacker head angle) we think we’ve made an even better trail bike.  The dropper ready, thru axle frame is fitted with the durable Revelation RC forks and the Deluxe RC Shock giving you complete adjustability for variations in terrain and condition. Sram Level T brakes and Vittoria Morsa, tubeless ready tyres take on the job of keeping you on the trails and Sram NX 11 Speed gears keep shifting hassle free as you focus on the next jump or berm. The Boardman MTR 8.9 Mountain Bike is designed to take on the worst that British trails can throw at you.

    • Frame: Lightweight alloy frame with updated 2018 geometry and dropper post routing
    • Forks: Revelation RC forks matched to Deluxe RC shock offers full adjustability
    • Gears: Sram NX 11 speed offers a great range of reliable gearing for all climbs and descents.
    • Brakes: Powerful Sram Level T brakes with adjustable levers
    • Wheels: Tubeless ready rims fitted with the Vitorria Morsa tyre, made to increase gripping power.

    Click to find out more about our new Boardman range

    Boardman MTR 8.9 Mountain Bike Extra Info

    • FREE build
    • Unlimited lifetime safety checks
    • Lifetime guarantee on frames and rigid forks*
    • Performance Hydraulic Cyclecare available

    *Please see our T&C's here

    Size Guide

    Height (Inch) Height (cm) Frame Size
    5' 3" - 5' 8" 160 - 172 Small
    5' 6" - 5' 11" 167 - 180 Medium
    5' 9" - 6'2" 175 - 188 Large
    6' 0" - 6' 5" 183 - 195 X Large

    Geometry Table

    Size S M L XL
    Stack 592mm 601mm 610mm 624mm
    Reach 416mm 438mm 455mm 466mm
    Seat Tube 410mm 432mm 460mm 483mm
    TT Top Tube 586mm 610mm 630mm 645mm
    HT Head Tube 110mm 120mm 130mm 145mm
    Travel 140mm 140mm 140mm 140mm
    FO Fork Offset 42mm 42mm 42mm 42mm
    HA Head Angle 67° 67° 67° 67°
    SA Seat Angle 73.5° 73° 73° 73°
    CS Chain Stay 425mm 425mm 425mm 425mm
    BB Bottom Bracket Drop 17mm 17mm 17mm 17mm
    Crank Length 175mm 175mm 175mm 175mm
    Stem Length 45mm 45mm 45mm 45mm
    Handlebar Width 720mm 740mm 740mm 740mm
    Seatpost Length 350mm 350mm 400mm 400mm
  • Approximate Weight (KG): 14.0kg
    Brake Type: Hydraulic Disc
    Forks: Rock Shox Revelation RC
    Frame Material: 6061 Alloy
    Gender: Mens
    Number of Gears: 11
    Pedals Included: Yes
    Suspension: Front Suspension
    Wheel Size: 27.5"
    Bottom Bracket: Sram GXP
    Cassette/Freewheel: Sram PG1130, 11 speed, 11-42t
    Chain: Sram PC1110
    Chainset: Sram NX GXP 32t, S - 170mm, M/L - 175mm
    Fork Lock-out: Yes
    Fork travel: 140mm
    Forks - Adjustable damping: Yes
    Frame: 6061 Alloy, smooth welds, internal dropper ready
    Front Brake: Sram Level T, 180mm rotor
    Front Hub: 6 bolt alloy, 15x110mm boost
    Gear Shifters: Sram NX 11 speed
    Geometry: Boardman MTB 2018
    Grips: Boardman Tapered lock-on by Velo
    Handlebars: Boardman alloy, 31.8mm clamp, 15mm rise, 9 degree bend, S - 720mm, M/L/XL - 740mm
    Headset: FSA Orbit No.52 (1.5" to 1 1/8" integrated )
    Pedals: Wellgo alloy flats, 9/16"
    Quick Release Front Wheel: No
    Quick Release Rear Wheel: No
    Rear Brake: Sram Level T, 160mm rotor
    Rear Hub: 12x148mm boost rear (M12xP1.5 axle)
    Rear Mech: Sram NX 11 speed, long cage
    Rear Shock: Rock Shox Deluxe RT 210x55mm
    Rear wheel travel: 140mm
    Rims: Boardman alloy, 32h, 27.5", tubeless-ready
    Saddle: Boardman MTB by Velo, black steel rails
    Seatpost: Boardman black alloy 31.6mm, S - 350mm, M/L/XL - 400mm (Seat clamp 34.9 Q/R)
    Stem: Boardman alloy, 31.8mm clamp, 45mm length
    Type: Mountain Bikes
    Tyre Size: 27.5x2.3"
    Tyres: Vittoria Morsa TNT (Tubeless ready, 120 TPI)
  • Boardman MTR 8.9 Mountain Bike is rated 4.4 out of 5 by 5.
    Rated 4 out of 5 by from Not as good as FSPro This may have a snazzy new frame but every other component is a massive step down from the outgoing FSPro. Level instead of Guide, NX instead of GX and Rev instead of Pike. And the checky buggers want a hundred quid more for it. If you can still find an FS Pro buy it instead, especially if you can get the version with FSA Comet cranks.
    Date published: 2018-09-10
    Rated 3 out of 5 by from It's basically a downgraded fs pro with a curved top tube I have the 2016 fs pro, and my brother has just bought this one when they launched, It does look nice and rides well. However we both agree that If you haven't ridden the fs pro, you will be over the moon. However if you have ridden the vs pro, this 8.9 feels like a huge downgrade. The fork, rear shock, brakes drivetrain and wheels have all been downgraded., compared to the pro. The bike feels heavier and sluggish in comparison and just doesnt ride as effortlessly as the pro fs. The brakes have no where near the same feel or bite as the guides either. It is a great bike, it's just no where near the bargain the fs pro was and still is. I recommend you wait until it is in a sale.
    Date published: 2018-08-14
    Rated 5 out of 5 by from JUST SIMPLY STUNNING I bought this bike for better components SRAM finishing and the forks. However when I saw it I had to have I, the colour in pics doesn't do it justice, its a burnt red with black finishing looks incredible, its one of the best bikes I have ever seen. Then I rode it. . OMG this bike rides of anything like its not there, it descends like a DH bike and climbs like its made of paper. Its incredible, everyone who has a shot comes back with lock jaw. No one else is to buy this bike.......its mine I tell you.. Get off its mine. Just however they made this bike for this price is incredible. The brakes are powerful enough and Revelation forks is brilliant so solid but adjustable. Well done Boardman..
    Date published: 2018-06-12
    Rated 5 out of 5 by from Fantastic Bike The performance and quality of the new model of the Boardman is truly astonishing. WOW!
    Date published: 2018-04-19
    Rated 5 out of 5 by from great bike loving the new design from the old MTB PRO Collect My one today bike rides very nice and gears works well only bad points with this bike is the brakes its a down grade from the old MTB Pro the new bike has sram level T not the Sram Guide only down but great bike
    Date published: 2018-04-10
